It is my pleasure to say that this book ‘Drip & Sprinkler Irrigation’ has been found useful to the students, professionals and many other users. Some sort of errors was identified in its first edition. Necessary cares have been taken to omit these errors. I may hope that this book will serve the purpose of the users for understanding the design, implementation and maintenance of micro irrigation projects. I would like to thanks and acknowledge New India Publishing Agency (NIPA), New Delhi for the consistent support and persuasion in publishing this second edition.

Introduction Drip irrigation is an efficient method of application of water at the plant bottom at a rate nearly equal to the consumptive use rate of the plant, thereby minimizing the conventional water losses like percolation, runoff and evaporation from soil. It is a process of slow application of water on, above or beneath the soil by the surface, sub-surface, bubbler, and spray or pulse system. Fertilizer can also be applied with the drip water. Emitters or applicators are placed closed to the plants and used to spray water in the form of drops, tiny streams or miniature spray. In the drip system water applied from the point source advances in all direction in the soil outward from the source. Drip irrigation is essentially a low rate, low pressure, frequent and long duration application of water in plants root zone area. Drip irrigation is also called as localized irrigation, trickle irrigation, daily f low irrigation, diurnal irrigation, drop irrigation, sip irrigation, and micro irrigation. A particular name is being popularized in any area depending on the choice of the people of that area. The International Commission for Irrigation and Drainage (ICID) has recommended the term micro-irrigation while the American Society of Agricultural Engineers (ASAE) has preferred drip irrigation. In India it is told as drip irrigation.

In drip irrigation water is distributed throughout the field from a system of pressurized pipelines. The pressure must be sufficient to overcome the frictional losses and elevation differences. The system also deserves discharge from all the emitters and the emitters must dissipate the pressure difference between the inlet to emitters and atmospheric pressure. The flow through the drip pipes may be laminar or turbulent or a combination of both. The laminar flow is characterized by the layers of cylindrical tubes of which the maximum velocity is at the center about double of the average velocity. The turbulent flows having pulsatory cross current velocities and maximum velocity is about only 1.25 time of the average velocity. Turbulent f lows loss more energy than laminar flow due to development of the cross current velocity. Reynolds Number The criterion for distinguishing the flow from laminar to turbulent was developed by Osborne Reynolds (1842-1900) and was named as Reynolds number; Re . The Reynolds number in circular pipes flowing full is expressed as

Crop Water Requirements In designing an irrigation system, the primary objective is to know the water requirement of crops. Water requirement of crops are determined either by f ield cultivation or by estimation through commonly used empirical formulae such as Blaney Criddle, radiation, Penman or pan evaporation method. Definitions Crop water requirement or evapotranspiration (ETcrop ): It may be defined as the rate of evapotranspiration of a disease free crop growing in a field of not less than one hectare under adequate fertility and water supply so that full productive potential can be achieved in prevailing environment. Evapotranspiration requirement of a crop refers the ETcrop and expressed in mm/day. Reference crop evapotranspiration (ET0 ): It is the rate of evapotranspiration from an extended surface of 8 to 15cm tall green grass of uniform height, actively growing, completely shading the ground and not short of water. ET0 may be computed by using the empirical formulae and meteorological data for the specific period.

The pipe network in a drip system consists of a mainline, sub mains, laterals, and distributors. The layout of the pipes depends on the physical factors like shape and size of the area, topography and any other obstacles in the field. In any field there may be the scope of different layout of the pipes. The most economic one should be selected. In general, contour line is followed in laying the laterals in sloping land, sub main length usually be shorten in uphill and equally spaced laterals on either side of a sub main in a flat land provides good layout. Hydraulic Formulae /Head Losses in Pipes There are numerous equations for solving the head loss in pipes. The most commonly used are the Darcy-Weisbach, Hazen-William and Scobey’s.

Introduction There is different type of distributors available in the market. Depending on the basic principle of working they may be broadly classified into three major groups as below (FAO, 1980). i. Distributors in which head loss takes place through small diameter tubes ii. Distributors in which head loss takes place through some orifice control iii. Distributors in which head loss takes place through a vortex action There are many adaptations to distributors though the working distributors fall under the above stated basic principle. Tiny perforation in the laterals or porous materials allows leaking out the water serves the purpose of distributors. The compensating type distributors have long path in it to dissipate the energy and drips almost same rate within certain range of pressure variation. Whatever may be the distributors proposed to be used, the discharge characteristics should be known. The discharge characteristics should be provided by the manufacturers and preferably certified by any authorized body; otherwise to be tested by the designer before recommendation to large-scale use.

Introduction Fertilization is the application of fertilizer for the benefit of the crops. It may be traditional broadcasting or fertigation. In broadcasting method the fertilizer is applied in concentrated granular form. The size of the granules ranges from granular dust to pellet size. These solid fertilizers get dissolved by the rain or irrigated water to leach down the plat root zone. This method results uneven nutrient delivery due to uneven dissolving the fertilizer granules. It may cause burning of plant leaves and root system due to uneven and uncontrolled release of nutrients. Dry fertilizers can volatilize and release gases which may damage or burn the nearby foliage. Availability of fertilizer to the plant root zone largely depends on the temperature and availability of water to dissolve the fertilizers. In fertigation liquid or water-soluble fertilizer, soil amendments or other products required by the plants is either sprayed on to the plant material or applied to the plant bottom with irrigation water. Foliar application provides high rate of absorption of fertilizer through the leaf/stalk/branch structures of plants. Ground application also provides good consistency in making its way to root zone and plant absorption. Thus, the fertigation provides benefit of increased nutrient absorption; decrease water needs, and reduce the fertilizer and chemical use (Anonyms, 2005).

Drip system has great promise for efficient utilization of available irrigation water. In our country and elsewhere in the world the scientists are unanimously agreed to adopt drip irrigation method for higher application efficiency and thereby better use of scarce irrigation water. Saksena (1993) reported water losses of only 1-2% in drip irrigation in comparison to 6-9% in sprinkler and 30-35% in surface irrigation method. However, very small area compared to other methods of irrigation so far is irrigated by drip system in our country. Up to 2000 the total area under drip irrigation was 2,59,600 ha in India (Alam & Kumar, 2000). Initial high investment for drip network and pumping system, of course, are discouraging to the most of our farmers. Sharma & Abrol (1993) mentioned that in spite of the very encouraging results and attractive subsidies offered by the Govt. of India, the adoption of the drip irrigation system has not picked up to the expected level. Along with the other reasons they pointed out the high initial cost of the system and lack of research effort on developing cost-effective design suited to local condition are responsible for non-practice of drip irrigation at a considerable scale. Some research works has been conducted to find out low cost method of drip irrigation. Biswas (1998) developed a manually operated drip irrigation system made of bamboo mains, laterals and sub-laterals. The system and its performance are described below. Drip Network The main and laterals of the drip network were made of hollow bamboo pieces each of 3m lengths with 7.5cm and 4.0cm diameter respectively. The sub lateral or the emitters were the bamboo twigs of 0.25cm inside diameter and 1.05-1.10m length to suit the spacing between the plant rows. The mains and laterals were made for the required length in the field by jointing together the sections one after another (Fig. 7.1). The ends of two sections, which contact each other, were made such that one section easily gets inside the other for about 10-15cm.

Sprinkler irrigation is an advanced method of irrigation in which water is sprayed to air and allowed to fall on the ground similar to rainfall. The spraying of water occurs through nozzle connected to a network of pipes with water under pressure. The rate of application and area of coverage under a sprinkler is regulated by suitable selection of nozzle size and pressure in the system. History of Sprinkler Irrigation The sprinkler irrigation has started elsewhere in the world in the early part of twentieth century. Before 1920, sprinkler irrigation was limited to orchard, nurseries and intensive vegetable cultivation. The cost of sprinkler reduced considerably by the development of impact sprinkler and lightweight steel pipe with quick couplers in the 1930s. As a result, sprinkler irrigation began to spread in larger area and to the area of field crops. However, sprinkler irrigation developed mainly after the Second World War with the introduction of lightweight portable aluminum pipe. Sprinkler irrigation has started in India from mid of 1950s. Due to requirement of high initial investment, the average Indian farmers cannot afford the system and therefore the area under sprinkler irrigation in India was 0.66mha (approx.) out of total irrigated area of 87.80mHa in 1995 (INCID). The sprinkler irrigation was first introduced in India in hilly regions such as Western Ghats in Kerala, Tamil Nadu, Karnataka and in the North Eastern States especially by plantation owners for irrigating tea, coffee and cardamom crops. Since the cost of aluminum pipe is high, to replace it, High Density Polyethylene Pipe (HDPE)/PVC with suitable modification have been introduced in sprinkler system. However, the area under HDPE/PVC piping system is below 20% to the total area under sprinkler irrigation. The remaining area is cultivated under aluminum or steel based sets. The indigenous manufacturing of the system has started in India only 35-40 years ago and there are about fifty numbers of manufacturers till 1996 (INCID). The details of the cultivated area under sprinkler irrigation system in the world and in Indian States are given in Table 8.1 & 8.2 respectively.
